Nichia SMD LED UV NVSU119C 405nm 1420mW at 700mA 2.2W with PCB (10x10mm)

Nichia SMD LED UV NVSU119C 405nm 1420mW at 700mA 2.2W with PCB (10x10mm)

The NVSU119C has a UVA radiant power of 1420mW at 405nm wavelength, making it highly suitable for industrial and commercial applications
Nichia's fine selection of products allows for greater added value for professional processing
The NVSU119C is available with three different wavelengths, providing versatility for various applications
Fixtures with multiple LEDs can be used for disinfection, plant growth, ink or resin curing, and lithography for medical, industrial, and commercial applications
The NVSU119C has a 140-degree viewing angle and a compact size of 3.5x3.5x2.0mm
It is important to seek advice from our employees before ordering this product due to the potential danger of UV radiation.

128,29 RON 107,81 RON

Stoc >100 bucati

Cod Produs

14359.03

Nichia (Japonia) a inventat LED-ul albastru, in 1993, si LED-ul alb cativa ani mai tarziu. Pentru aceasta descoperire cercetatorii Nichia au primit in 2014 Premiul nobel pentru Fizica.

In prezent Nichia este cel mai mare producator de diode LED cu o cota de piata la nivel global de peste 30%. LED-urile Nichia albe si albastre sunt cele mai fiabile si performante LED-uri din lume. Spre exemplu seria 757G a depasita limita de eficienta luminoasa de 210 lm/watt.

The Nichia SMD LEDs in the UV range are highly versatile and can be used in a variety of applications. The NVSU119C is available with three different wavelengths, and at a 405nm wavelength, it reaches a power of 1420mW, making it ideal for industrial and commercial applications. Fixtures with multiple LEDs can be used for disinfection, plant growth, ink or resin curing, and lithography for medical, industrial, and commercial applications.

Nichia is one of the largest LED manufacturers in the world, and their innovative research department continues to pioneer new advances in the field of LED lighting solutions. Nichia is credited with inventing the blue LED, which led to the development of white LEDs. Durability, brightness, and homogeneity are some of the major strengths of the Nichia brand, and their fine selection allows for greater added value for professional processing.

It is important to note that UV radiation is invisible to the naked eye and can pose a danger to the eyes and skin even with short-term exposure. Before ordering this product, it is crucial to seek advice from our employees to ensure safety.

Features

SMD LED UVA with 1420mW radiant power at 405nm
Nichia 3535 Package
Forward current typ: 700mA at 3.1V
Forward current max: 1400mA at 3.5V
Power consumption: 2.2W at 700mA
140 degree viewing angle
Risk group 3 (EN 62471)
Dimensions LED (LxWxH): 3.5x3.5x2.0

Application areas

medical engineering
test and sorting machines
hardening
cameras with UV light

Warning Actinic UV danger for eyes and skin

Ultra violet radiation in the wavelength range of 200-400nm may cause inflammation of the cornea as well as a UV erythema (sunburn) of the skin. The biological effectiveness of the UV radiation varies in the stated wavelength range and is described with the spectral response function (weighting scale) SUV.

UV-A danger for the eyes

Ultra violet radiation in the wavelength range of 315-400nm (UV-A) is for the most part absorbed by the eye lens and may cause UV cataracts (clouding of the lens of the eye).

Date Tehnice
Cod Produs	14359.03
Greutate bruta (g)	1.000000
Dimensiuni LED	3.5x3.5 mm
Model LED	Nichia UV
LED recomandat pentru	Photocatalyst
Mod Instalare LED	LED pe placuta preasamblat
Culoare	UVA Ultraviolet
Unghi de iluminare	140°
Curent Recomandat	700mA
Tensiune Tipica (V)	3.1
Putere (W)	2.2
Lungime de unda (nm)	405
Cod Producator	NVSU119CT U405
Producator	Nichia
Disponibilitate dincolo de stocul afisat:	YES
Dimensiune: Lungime (cm)	0.35
Dimensiuni: Latime (mm)	0.20
Dimensiune: Inaltime (mm)	0.35
